0.4mm 섬유유리에 의하여 길쌈되는 직물 E 유리제 털실 M0 불 담요 Materia
Place of Origin:중국
Brand Name:SUNTEX
Model Number:GF430P
Minimum Order Quantity:20의 목록
Payment Terms:T/T; L/C, Paypal…
Supply Ability:500000SQM/month
Product Details
강조하다:
섬유유리에 의하여 길쌈되는 직물
,7628 섬유유리 피복
Application:
불 담요
Weight:
430g/sq.mtr
Working Temperature:
550 C
Property:
내화성
Color:
미색
Yarn:
E 유리
Product Description
0.4 밀리미터 섬유 유리 직물 방화 우븐 유리 섬유 M0 화재 블랭킷 재료
GF430P는 매체 중량 우븐 섬유 유리 직물입니다. 그것은 프리미엄 등급 직기상태 유리 섬유입니다.
미국 참조 3732 번.
GF430P는 열 절연 덥개, 방화막 / 덮개, 패딩과 다른 사격 지휘 장치의 제조사를 위해 설계됩니다.
GF430P는 또한 차이 탄성체와 폴리머로 덧입히는데 적합합니다.
기술 데이터 :
| 특성 데이터 | |||
| (측정) | (영어) | 검사 방법 | |
| 제직물 | 4H 진 | 미나리아재비 | |
| 방사 | |||
| 날실 | EC9 68 1*2 | ECG 75 1/2 | |
| 씨실 | EC9 68 1*2 | ECG 75 1/2 | |
| 구조 | |||
| 날실 | 18 ± 1 마지막 / 센티미터 | 48 ± 3 마지막 / 인치 | ASTM D 3775-96 |
| 씨실 | 12.6 ± 1은 / 센티미터를 고릅니다 | 32 ± 3은 / 인치를 고릅니다 | ASTM D 3775-96 |
| 중량 | 430 ± 20 g/m2 | 12.6 ± 0.58 oz/yd2 | ASTM D3776-96 |
| 두께 | 0.37 ± 0.02 밀리미터 | 0.0145 ± 0.0008 인치 | ASTM D1777-96 |
| 표준 폭 | 101.6 ± 1 센티미터 | 40 ± 0.39 인치 | ASTM D3776-96 |
| 155 ± 1 센티미터 | 61 ± 0.39 인치 | ||
| 인장 강도 | |||
| 날실 | 4816 N/5 센티미터 | 550 라이브프 / 인치 | ASTM D5034-95 |
| 씨실 | 3503 N/5 센티미터 | 400 라이브프 / 인치 | ASTM D5034-95 |
| 임시 저항 | 5500C | 10000F | |
장점 :
1.좋은 항발화성.M0 분류.
2.탄력적이고 부드럽고 제조되도록 쉽습니다
5.기온 550C 도를 지닙니다.
메인 애플리케이션 :
1. 방화용 모포.
2. 열 보호.
3. 코팅에 쓸 기재.
